80W LED Beam Moving Head Light
The Merak Beam 80 of LED beam moving head light brings Nebula’s no-compromise quality and performance. The intelligent sharpy moving head is with a bright 80W LED source which emits a concentrated solid beam with a beam angle 2°. The quality of its effects, high light output derive from the rigorous quality requirement of Nebula which is one of professional sharpy moving light manufacturer in China.
The moving head led 80w fits a fixed gobo wheel with 17 gobos, a color wheel with 15 colors, accompanying with frost effect and 8-facet circular rotating prism effect. The moving beam led 80w also features fast and smooth pan/tilt with contrasting movements, position memory and auto correction, linear focus, smoothly adjustable dimmer with 3 selectable dimmer curves, variable strobe, which can provide infinite possibilities for users creating wonderful sharpy light effect.
The moving beam 80w has 12/15Chs DMX Channel. The control modes of beam 80w includes DMX and manual. Users can set the configuration via the LED display panel. Normal display and inverted display are freely choose.
The 80w moving head beam enables a new world of expression in touring, live show, ceremony, event, TV, theater and installed lighting markets.
SOURCE
- Source: 80W White LED
- CT: 7000K
- Life: >20,000 hrs
POWER
- Power Supply: AC 100-240V, 50/60Hz
- Power Consumption: 110W
OPTICAL SYSTEM
- Pan/Tilt: 540°/270°, 16 bit resolution, position memory, auto correction
- Beam Angle: 2°
- Focus: Motorized linear focus
- Prism: 8-facet circular rotating prism ( linear prism, 2-independent-prism optional )
- Frost: 1 frost filter
- Dimmer: 0-100% smoothly adjustable
- Strobe: 0-20 Hz variable speed, pulse and random strobe
COLORS
- 1 Color Wheel with 15 colors + white, full and half color function, bi-directional rotation
FIXED GOBOS
- 1 fixed Gobo Wheel with 17 gobos + open, shake and bi-directional rotation
CONTROL & CONNECTION
- DMX Channel: 12/15 CHs
- Control Mode: DMX512, Manual
- Connection: 3 pin &5 pin XLR
WEIGHT & DIMENSION
- Net Weight: 13.45 kg
- Dimension: 349×240×536mm
*The specification of Nebula 80w led beam moving head subject to change without notice. All rights reserved.
- Beam optics and impressive performance
- Extremely narrow beam of 2 degree
- High light output
- Motorised linear focus lens
- One color wheel with 15 Colors
- One fixed gobo wheel with 17 Gobos
- Rotating 8-facet circular prism
- Smooth adjustable dimmer
- DMX channels 12ch / 15ch
The outlook of Nebula 80w led beam light is fashionable from the dimensional drawing.
The 80W led beam light fits 17 static gobos, 15 dichoric colors.
- Specification
-
SOURCE
- Source: 80W White LED
- CT: 7000K
- Life: >20,000 hrs
POWER
- Power Supply: AC 100-240V, 50/60Hz
- Power Consumption: 110W
OPTICAL SYSTEM
- Pan/Tilt: 540°/270°, 16 bit resolution, position memory, auto correction
- Beam Angle: 2°
- Focus: Motorized linear focus
- Prism: 8-facet circular rotating prism ( linear prism, 2-independent-prism optional )
- Frost: 1 frost filter
- Dimmer: 0-100% smoothly adjustable
- Strobe: 0-20 Hz variable speed, pulse and random strobe
COLORS
- 1 Color Wheel with 15 colors + white, full and half color function, bi-directional rotation
FIXED GOBOS
- 1 fixed Gobo Wheel with 17 gobos + open, shake and bi-directional rotation
CONTROL & CONNECTION
- DMX Channel: 12/15 CHs
- Control Mode: DMX512, Manual
- Connection: 3 pin &5 pin XLR
WEIGHT & DIMENSION
- Net Weight: 13.45 kg
- Dimension: 349×240×536mm
*The specification of Nebula 80w led beam moving head subject to change without notice. All rights reserved.
- Advantage
-
- Beam optics and impressive performance
- Extremely narrow beam of 2 degree
- High light output
- Motorised linear focus lens
- One color wheel with 15 Colors
- One fixed gobo wheel with 17 Gobos
- Rotating 8-facet circular prism
- Smooth adjustable dimmer
- DMX channels 12ch / 15ch
- Dimensional Drawing
-
The outlook of Nebula 80w led beam light is fashionable from the dimensional drawing.
- DMX Chart & Lighting Effect
-
- Colors & Gobos
-
The 80W led beam light fits 17 static gobos, 15 dichoric colors.
- Video
-
- Download
